Attributes for item 15-13272
Model (in.):
3
Technical Construction:
Bolted
Wetted Path Material:
Aluminum
Diaphragm Material:
Santoprene®
Diaphragm Design:
TPE IPD
Diaphragm Stroke:
Full-Stroke
Connection Standard:
ANSI
Inlet Size (in.):
3.0
Inlet Orientation:
Center Horizontal Back
Discharge Size (in.):
3.0
Discharge Orientation:
Center Horizontal Front
Outer Piston Materials:
No Outer Piston
Air Side Material:
Aluminum
Valve Material:
Santoprene®
Valve Type:
Valve Ball
Valve Seat MATERIAL:
Aluminum
O Rings Gasket Material:
EPDM
Hardware Material:
Diaphragm Dependent
Muffler Material:
Aluminum
Self Priming:
TRUE
Power Source:
Compressed Air
Max Operating Temperature (°F):
225.0
Min Operating Temperature (°F):
-40.0
Atex Rated:
TRUE
CE:
TRUE
UKCA:
TRUE
FDA:
FALSE
3A:
FALSE
EHEDGE:
FALSE
UL:
FALSE
CSA:
FALSE
Shipping Weight (lbs):
189
Country Of Origin:
USA
