Attributes for item 15-11388
Model (in.):
3
Technical Construction:
Bolted
Wetted Path Material:
Aluminum
Diaphragm Material:
Neoprene
Diaphragm Design:
TRADITIONAL
Diaphragm Stroke:
Full-Stroke
Connection Standard:
DIN
Inlet Size (in.):
3.0
Inlet Orientation:
Center Horizontal Back
Discharge Size (in.):
3.0
Discharge Orientation:
Center Horizontal Front
Outer Piston Materials:
Aluminum
Air Side Material:
Aluminum
Valve Material:
Neoprene
Valve Type:
Flap Valve
Valve Seat MATERIAL:
Aluminum
O Rings Gasket Material:
Neoprene
Hardware Material:
Diaphragm Dependent
Muffler Material:
Aluminum
Self Priming:
TRUE
Power Source:
Compressed Air
Air Inlet Connection:
3/4" FNPT
Max Operating Temperature (°F):
200.0
Min Operating Temperature (°F):
0.0
Atex Rated:
FALSE
CE:
TRUE
UKCA:
TRUE
FDA:
FALSE
3A:
FALSE
EHEDGE:
FALSE
UL:
FALSE
CSA:
FALSE
Shipping Weight (lbs):
240
Country Of Origin:
USA
