Attributes for item 08-15701
Model (in.):
2
Technical Construction:
BOLTED
Wetted Path Material:
ALUMINUM
Diaphragm Material:
Neoprene
Diaphragm Design:
TRADITIONAL
Diaphragm Stroke:
Full-Stroke
Connection Standard:
NPT
Inlet Size (in.):
2.0
Inlet Orientation:
CENTER HORIZONTAL BACK
Discharge Size (in.):
2.0
Discharge Orientation:
CENTER HORIZONTAL FRONT
Outer Piston Materials:
MILD STEEL
Air Side Material:
ALUMINUM
Valve Material:
NEOPRENE
Valve Type:
FLAP VALVE
Valve Seat MATERIAL:
MILD STEEL
O Rings Gasket Material:
NEOPRENE
Hardware Material:
DIAPHRAGM DEPENDENT
Muffler Material:
Aluminum
Self Priming:
YES
Power Source:
COMPRESSED AIR
Air Inlet Connection:
3/4" FNPT
Max Operating Temperature (°F):
200.0
Min Operating Temperature (°F):
0.0
Atex Rated:
YES
CE:
YES
UKCA:
YES
FDA:
NO
3A:
NO
EHEDGE:
NO
UL:
NO
CSA:
NO
Shipping Weight (lbs):
95
Shipping Dimensions:
25" W X 19" L X 21.25" H
Country Of Origin:
UNITIED STATES
