Attributes for item 08-15158
Model (in.):
2
Technical Construction:
Bolted
Wetted Path Material:
Iron
Diaphragm Material:
Neoprene
Diaphragm Design:
TRADITIONAL
Diaphragm Stroke:
Full-Stroke
Connection Standard:
NPT
Inlet Size (in.):
2.0
Inlet Orientation:
Center Horizontal Back
Discharge Size (in.):
2.0
Discharge Orientation:
Center Horizontal Front
Outer Piston Materials:
Mild Steel
Air Side Material:
Aluminum
Valve Material:
Neoprene
Valve Type:
Flap Valve
Valve Seat MATERIAL:
Mild Steel
O Rings Gasket Material:
Neoprene
Hardware Material:
Diaphragm Dependent
Muffler Material:
Aluminum
Self Priming:
TRUE
Power Source:
Compressed Air
Max Operating Temperature (°F):
200.0
Min Operating Temperature (°F):
0.0
Atex Rated:
TRUE
CE:
TRUE
UKCA:
TRUE
FDA:
FALSE
3A:
FALSE
EHEDGE:
FALSE
UL:
FALSE
CSA:
FALSE
Shipping Weight (lbs):
145
Shipping Dimensions:
25" W X 19" L X 21.25" H
Country Of Origin:
USA
