Attributes
Model:
1.5
Technical Construction:
BOLTED
Wetted Path Material:
ALUMINUM
Diaphragm Material:
Bunalast™
Diaphragm Design:
EZ-INSTALL
Diaphragm Stroke:
Full-Stroke
Connection Standard:
NPT
Inlet Size:
1.5
Inlet Orientation:
CENTER HORIZONTAL BACK
Discharge Size:
1.5
Discharge Orientation:
CENTER HORIZONTAL FRONT
Outer Piston Materials:
ALUMINUM
Air Side Material:
POLYPROPYLENE
Valve Material:
Buna-N
Valve Type:
VALVE BALL
Valve Seat MATERIAL:
Buna-N
O Rings Gasket Material:
Buna-N
Hardware Material:
DIAPHRAGM DEPENDENT
Muffler Material:
Aluminum
Self Priming:
YES
Power Source:
COMPRESSED AIR
Air Inlet Connection:
FNPT
Maximum Allowable Operating Pressure:
125.0
Max Air Pressure:
125.0
Max Diameter Solids:
0.25
Max Flow Rate:
130.0
Flow Rate 40 Psi:
104.0
Flow Rate 50 Psi:
92.0
Flow Rate 60 Psi:
86.0
Flow Rate 70 Psi:
78.0
Flow Rate 80 Psi:
67.0
Flow Rate 90 Psi:
58.0
Flow Rate 100 Psi:
46.0
Flow Rate 120 Psi:
0.0
Max Suction Lift Dry:
15.9
Max Operating Temperature:
175.0
Min Operating Temperature:
32.0
Max Viscosity:
125000
Max Air Consumption:
130.0
Atex Rated:
NO
CE:
YES
UKCA:
YES
FDA:
NO
3A:
NO
EHEDGE:
NO
UL:
NO
CSA:
NO
Shipping Weight:
57
Shipping Dimensions:
17.88" W X 13.75" L X 22.19" H
Country Of Origin:
UNITIED STATES
