Attributes
Model:
1.5
Technical Construction:
CLAMPED
Wetted Path Material:
STAINLESS STEEL
Diaphragm Material:
PTFE
Diaphragm Design:
TRADITIONAL
Diaphragm Stroke:
Full-Stroke
Connection Standard:
TRI-CLAMP
Inlet Size:
1.5
Inlet Orientation:
CENTER HORIZONTAL BACK
Discharge Size:
1.5
Discharge Orientation:
CENTER VERTICAL
Outer Piston Materials:
STAINLESS STEEL
Air Side Material:
ALUMINUM
Valve Material:
PTFE
Valve Type:
VALVE BALL
Valve Seat MATERIAL:
HYTREL
O Rings Gasket Material:
HYTREL
Hardware Material:
STAINLESS STEEL
Muffler Material:
Aluminum
Self Priming:
YES
Power Source:
COMPRESSED AIR
Air Inlet Connection:
.75" FNPT
Maximum Allowable Operating Pressure:
125.0
Max Air Pressure:
125.0
Max Flow Rate:
99.0
Flow Rate 40 Psi:
81.0
Flow Rate 50 Psi:
75.0
Flow Rate 60 Psi:
77.0
Flow Rate 70 Psi:
60.0
Flow Rate 80 Psi:
50.0
Flow Rate 90 Psi:
37.0
Flow Rate 100 Psi:
24.0
Flow Rate 120 Psi:
0.0
Max Suction Lift Dry:
22.9
Max Operating Temperature:
220.0
Min Operating Temperature:
40.0
Max Viscosity:
125000
Max Air Consumption:
83.0
Atex Rated:
YES
CE:
YES
UKCA:
YES
FDA:
YES
3A:
NO
EHEDGE:
NO
UL:
NO
CSA:
NO
Shipping Weight:
62
Shipping Dimensions:
16.25" W X 14.13" L X 18.5" H
Country Of Origin:
UNITIED STATES
