Attributes
Model:
1
Technical Construction:
CLAMPED
Wetted Path Material:
STAINLESS STEEL
Diaphragm Material:
PTFE
Diaphragm Design:
TRADITIONAL
Diaphragm Stroke:
Full-Stroke
Connection Standard:
NPT
Inlet Size:
1.0
Inlet Orientation:
CENTER HORIZONTAL BACK
Discharge Size:
1.0
Discharge Orientation:
CENTER HORIZONTAL FRONT
Outer Piston Materials:
STAINLESS STEEL
Air Side Material:
POLYPROPYLENE
Valve Material:
PTFE
Valve Type:
VALVE BALL
Valve Seat MATERIAL:
STAINLESS STEEL
O Rings Gasket Material:
PTFE
Hardware Material:
STAINLESS STEEL
Muffler Material:
Plastic
Self Priming:
YES
Power Source:
COMPRESSED AIR
Air Inlet Connection:
.25" FNPT
Maximum Allowable Operating Pressure:
120.0
Max Air Pressure:
120.0
Max Diameter Solids:
0.13
Max Flow Rate:
44.0
Flow Rate 40 Psi:
39.0
Flow Rate 50 Psi:
37.0
Flow Rate 60 Psi:
35.0
Flow Rate 70 Psi:
33.0
Flow Rate 80 Psi:
30.0
Flow Rate 90 Psi:
28.0
Flow Rate 100 Psi:
25.0
Flow Rate 120 Psi:
0.0
Max Suction Lift Dry:
15.3
Max Operating Temperature:
175.0
Min Operating Temperature:
40.0
Max Viscosity:
125000
Max Air Consumption:
65.0
Atex Rated:
NO
CE:
YES
UKCA:
YES
FDA:
NO
3A:
NO
EHEDGE:
NO
UL:
NO
CSA:
NO
Shipping Weight:
37
Shipping Dimensions:
11.75" W X 11.75" L X 12.13" H
Country Of Origin:
UNITIED STATES
