Attributes for item 01-11363
Model (in.):
0.5
Technical Construction:
CLAMPED
Wetted Path Material:
STAINLESS STEEL
Diaphragm Material:
FKM
Diaphragm Design:
TRADITIONAL
Diaphragm Stroke:
Full-Stroke
Connection Standard:
TRI-CLAMP
Inlet Size (in.):
0.5
Inlet Orientation:
CENTER SWIVEL
Discharge Size (in.):
0.5
Discharge Orientation:
CENTER SWIVEL
Outer Piston Materials:
STAINLESS STEEL
Air Side Material:
ALUMINUM
Valve Material:
FKM
Valve Type:
VALVE BALL
Valve Seat MATERIAL:
STAINLESS STEEL
O Rings Gasket Material:
PTFE
Hardware Material:
STAINLESS STEEL
Muffler Material:
Aluminum
Self Priming:
YES
Power Source:
COMPRESSED AIR
Air Inlet Connection:
1/2" FNPT
Maximum Allowable Operating Pressure (psig):
125.0
Max Air Pressure (psig):
125.0
Max Diameter Solids (in.):
0.06
Max Flow Rate (gpm):
15.9
Flow Rate 40 Psi (gpm):
14.0
Flow Rate 50 Psi (gpm):
13.5
Flow Rate 60 Psi (gpm):
12.8
Flow Rate 70 Psi (gpm):
12.0
Flow Rate 80 Psi (gpm):
11.0
Flow Rate 90 Psi (gpm):
9.0
Flow Rate 100 Psi (gpm):
6.0
Flow Rate 120 Psi (gpm):
0.0
Max Suction Lift Dry (ft.):
19.3
Max Operating Temperature (°F):
220.0
Min Operating Temperature (°F):
40.0
Max Air Consumption (psi):
17.0
Atex Rated:
YES
CE:
YES
UKCA:
YES
FDA:
NO
3A:
NO
EHEDGE:
NO
UL:
NO
CSA:
NO
Shipping Dimensions:
10.75" W X 10" L X 11" H
Country Of Origin:
UNITIED STATES
