Attributes for item 01-11265
Model (in.):
0.5
Technical Construction:
CLAMPED
Wetted Path Material:
ALUMINUM
Diaphragm Material:
Hytrel®
Diaphragm Design:
TRADITIONAL SANITARY
Diaphragm Stroke:
Full-Stroke
Connection Standard:
NPT
Inlet Size (in.):
0.5
Inlet Orientation:
CENTER SWIVEL
Discharge Size (in.):
0.5
Discharge Orientation:
CENTER SWIVEL
Outer Piston Materials:
ALUMINUM
Air Side Material:
ALUMINUM
Valve Material:
Hytrel®
Valve Type:
VALVE BALL
Valve Seat MATERIAL:
ALUMINUM
O Rings Gasket Material:
HYTREL
Hardware Material:
DIAPHRAGM DEPENDENT
Muffler Material:
Aluminum
Self Priming:
YES
Power Source:
COMPRESSED AIR
Air Inlet Connection:
1/2" NPT
Maximum Allowable Operating Pressure (psig):
125.0
Max Air Pressure (psig):
125.0
Max Diameter Solids (in.):
0.06
Max Flow Rate (gpm):
15.9
Flow Rate 40 Psi (gpm):
14.4
Flow Rate 50 Psi (gpm):
13.8
Flow Rate 60 Psi (gpm):
13.4
Flow Rate 70 Psi (gpm):
12.6
Flow Rate 80 Psi (gpm):
11.6
Flow Rate 90 Psi (gpm):
9.8
Flow Rate 100 Psi (gpm):
5.5
Flow Rate 120 Psi (gpm):
0.0
Max Suction Lift Dry (ft.):
18.7
Max Operating Temperature (°F):
220.0
Min Operating Temperature (°F):
-20.0
Max Air Consumption (psi):
18.0
Atex Rated:
YES
CE:
YES
UKCA:
YES
FDA:
NO
3A:
NO
EHEDGE:
NO
UL:
NO
CSA:
NO
Shipping Weight (lbs):
13
Shipping Dimensions:
10.75" W X 10" L X 11" H
Country Of Origin:
UNITIED STATES
