Attributes for item A025-SQP-STPE-Y70
Model (in.):
0.25
Technical Construction:
BOLTED
Wetted Path Material:
POLYPROPYLENE
Diaphragm Material:
Santoprene®
Diaphragm Design:
TRADITIONAL
Diaphragm Stroke:
Full-Stroke
Connection Standard:
FNPS (FNPT/FBSP)
Inlet Size (in.):
0.25
Inlet Orientation:
SIDE LEFT
Discharge Size (in.):
0.25
Discharge Orientation:
SIDE LEFT
Outer Piston Materials:
POLYPROPYLENE
Air Side Material:
POLYPROPYLENE
Valve Material:
PTFE
Valve Type:
BALL
Valve Seat MATERIAL:
POLYPROPYLENE
O Rings Gasket Material:
EPDM
Hardware Material:
SS
Muffler Material:
PLASTIC
Self Priming:
YES
Power Source:
COMPRESSED AIR
Air Inlet Connection:
1/4" FNPT
Maximum Allowable Operating Pressure (psig):
120.0
Max Air Pressure (psig):
120.0
Max Diameter Solids (in.):
0.06
Max Flow Rate (gpm):
5.7
Flow Rate 60 Psi (gpm):
3.0
Flow Rate 70 Psi (gpm):
2.4
Flow Rate 80 Psi (gpm):
1.7
Flow Rate 100 Psi (gpm):
0.7
Flow Rate 120 Psi (gpm):
0.0
Max Suction Lift Dry (ft.):
14.0
Max Suction Lift Wet (ft.):
28.0
Max Operating Temperature (°F):
180.0
Min Operating Temperature (°F):
32.0
Max Viscosity (cP):
25185
Max Air Consumption (psi):
5.5
Atex Rated:
NO
CE:
YES
UKCA:
YES
FDA:
NO
3A:
NO
UL:
NO
CSA:
NO
Shipping Weight (lbs):
6
Shipping Dimensions:
6"X6"X8"
Country Of Origin:
USA
